Now you are at> Machine types >Specialized Cuff Knitting Machine

Description of Machine
Model: CH-CG01 Specialized Cuff Knitting Machine
Diameter /
Gague
Cylinder Diameter : 4〞, 4.5〞, 5〞, 6〞 ; 4 Feeders
Guauge: 1.5G to 16G
R. P. M.

4〞 approx. 100, 4.5〞 approx.90, 5〞 approx.90, 6〞 approx.80

Capacity: Cuff:400 pcs/ 8h;Cuff:4800”/ 8h.
Power: 1/2 HP ~1HP ; Voltage 220/380/415 ; 3 Phase and 50/60 HZ
(the voltage and frequency of motor can be appointed at the request of customer.)
Machine Weight:

Space Occupied:110 CM x 100 CM x 300 CM
WORKING SPACE: 150 CM x 150 CM x 300 CM

Working Area: N.W.: 310 KGS to 325 KGS / G.W.: 460 KGS to 480 KGS
Hot Cylinder Diameter: 4〞 4.5〞 5〞 6〞
Needles of Number(8G) 100N x 100N 112N x 112N 126N x 126N 152N x 152N
Needles of Number(10G)

126N x 126N

144N x 144N 160N x 160N 192N x 192N
Application:

Suitable for all kinds of yarns such as Cotton, Spun Polyester, Single Cover Spandex, Double Cover Spandex, Recycled Yarn, Latex, Lycra, Acrylic, Wool Blended Yarn, Thermal Yarn, Cooling Yarn, Moisture Absorption Yarn, Thermo-fusible Adhering Yarn, Antibacterial Yarn, Functional Yarn, Core Spun Spandex Yarn, Graphene Yarn, Coffee Yarn, Coconut Charcoal Yarn, Angora Yarn, Collagen functional yarn, silver electro conductive yarn, Metal Cover yarn, Charcoal Fiber Yarn, Flame Retardant Eco-yarn, Cashmere yarn, Merino Wool Yarn and etc…

Available 30D to 600D, Ne 60/1 to Nm 1/2

Feature:

When needles break, yarn break or the collecting bucket is full, the electric system will sense it and cut off the motor power to stop the machine, so it could reduce the loss of material and the damage, also it is easier to repair.
The circular knitting machine with excellent design could produce small seamless tubular fabrics with high flexible.
6 ways adjustable feeders are easy for technician to adjust the position freely.
The medium hardness brush is to reduce the chance of needles crash and to enhance the needles using life.
For improve the quality of fabrics and reduce the loss, It is able to purchase extra system such as mechanical feeding system or electrical feeding system.
For enhance the flexible and pressure of fabrics, it is able to purchase the feeding system for Lycra, OP, Spandex or Latex cover yarns.
4 Feeders, fixed material per feeder, fix color.
It is able to make 4 color frequency grain knitting fabrics at maximum. Each feeder could feed surface yarn and based yarn at the same time.
The horizontal Top Needles and vertical jacquard needle are all adjustable, technician could adjust the setting freely, such as 2 feeders feed yarn and the other stops, or 3 feeders feed yarn and the other stop.

Application Products.:

Hats or Bennies, or baby warming products. Tube can apply to socks, or medical use products, such as tube for skin protection after bone surgery, or wrist cuff for isolation gown (suits), same as wrist cuff for protective clothing, and wrist cuff for chemical coverall suits, wrist cuff for discard suits, wrist cuff for disposable suits, the cuff of raincoat, the cuff of goalkeeper gloves,
