Double Side Computerized Jacquard Machine
Model: CH-CGJ01-C
Application:
Suitable for all kinds of yarns. Pure cotton, synthetic yarn and blended fabrics.
Features:

(1) The machine possesses excellent design, solid structure and easy operation. And beginner can easily operate it.
(2) Pattern and setting up parameter can be saved in USB input and output.
(3) Possibility of 4 color plus ground on the same line.
(4) One main feed plus three pattern feeds on the same course.
(5) Pattern Depth up to 480,000 dots. (BMP)
(6) Actuator can be chosen freely during 8 butts.
(7) For differing way of knitting. It can purchase optional parts.

Cylinder Diameter: 4〞to 16〞.
Gauge: Below 18G(Double side)。
Number of Needle:

It can be appointed at the request of customer.

Power: 1/2 HP ~1HP (The voltage and frequency of motor can be appointed at the request of customer.)
R. P. M.

10〞to 50/8〞to 60/4〞to 70.

Space Occupied: 110CM X 100CM
Height: 300CM
Specification of Machine
Size 6〞 7〞 8 1/2〞 10〞
Net Weight 290KGS 310KGS 320KGS 330KGS
Gross Weight 395KGS 450KGS 460KGS 470KGS
Packing Dimensions

120 cm x 87 cm x 220 cm

125 cm x 102 cm x 220 cm

138 cm x 109 cm x 220 cm 138 cm x 109 cm x 220 cm
