Double Side Computerized Jacquard Machine(Protector Series)
Model: CH-CGJ01-C
Application:
Suitable for all kinds of yarns. Pure cotton, synthetic yarn and blended fabrics.
Features:

(1)The machine possesses excellent design, solid structure and easy operation. And beginner can easily operate it.
(2)Pattern and setting up parameter can be saved in USB and output.
(3)Possibility of 4 color plus ground on the same line.
(4)One main feed plus three pattern feeds on the same course.
(5)Pattern Depth up to 480,000 dots. (BMP)
(6)Available in 220/380/415V, 3phase 50/60Hz.
(7)Actuator can be chosen freely during 8 butts.
(8)For differing way of knitting. It can purchase optional parts.

Cylinder Diameter: 4〞to16〞
Gauge: Below 18G. (Double side)
Number of Needle:

It can be appointed at the request of customer.

Power: 1/2 HP ~1HP(the voltage and the frequency of motor can be appointed at the request of customer)
R. P. M.

10〞to 50/8〞to 60/4〞to 70

Space Occupied: 110CM X 100CM
Height: 300CM
Specification of Machine
Size 6〞 7〞 8 1/2〞 10〞
Net Weight 290KGS 310KGS 320KGS 330KGS
Gross Weight 395KGS 450KGS 460KGS 470KGS
Packing Dimensions

120 cm x 87cm x 220 cm

125 cm x 102 cm x 220 cm

138 cm x 109 cm x 220 cm 138 cm x 109 cm x 220 cm
